Processor Model:
|
Intel® Xeon® Processor E5-2600 v4 Series
|
|
Max Processors:
|
Two
|
|
Max Cores Per System:
|
44
|
|
Max Threads Per System:
|
88
|
|
Storage Controller:
|
None (for All-Flash configuration) or Internal 12 Gb SAS RAID HBA or Internal 12 Gb SAS HBA
|
|
Built-In Security:
|
TPM, FIPS 140-2 Compliant mode, Encrypted Storage Redirection
|
|
Max System Memory:
|
12 or 24 DIMMs, up to 384 GB or 768 GB
|
|
Reliability, Availability & Serviceability (RAS):
|
Hot-swappable disk drives, redundant and hot-swappable power supplies and fans
|
|
Manageability:
|
Complete individual server management tools are included at no additional charge. Premier Support for Systems includes access to My Oracle Support and Oracle Enterprise Manager Ops Center multi server management.
|
|
Maximum Number of Disk Drives:
|
8, 14 or 26
|
|
Largest Available Drive Size:
|
1.2 TB 2.5-inch or 8 TB 3.5-inch
|
|
Maximum Drive Spindle Speed:
|
10,000 rpm 2.5-inch or 7200 rpm 3.5-inch
|
|
Drive Protocol:
|
SAS-3
|
|
Physical Size:
|
2.5-inch or 3.5-inch
|
|
Maximum Number of Solid State Drives:
|
2, 8 or 26
|
|
Largest Available Solid State Drive Size:
|
400 GB
|
|
Maximum Number of NVM Express Drives:
|
4 (zero supported in single-CPU configs)
|
|
Largest Available NVM Express Drive Size:
|
3.2 TB
|
|
DVD-RW:
|
Yes with 8 disk drive disk cage version only
|
|
LAN on Mother Board:
|
Four onboard 10GBase-T ports (only two active for single-cpu configs)
|
|
USB Ports:
|
Six
|
|
Serial Ports:
|
One
|
|
Video Ports:
|
One
|
|
Fibre Optic Ports:
|
None on Motherboard
|
|
PCIe Slots:
|
Up to six PCIe 3.0 (only three active for single-cpu configs) and one internal slot for SAS/RAID HBA
|
|
Total Slots:
|
6
|
|
Power/ Cooling:
|
Redundant and hot-swappable
|
|
Power Supply Type:
|
Platinum Plus rated, 1000W 100-240 VAC
|
|
Form Factor:
|
Rack Server
|
|
Rack Units:
|
2
|
|
Operating System/Software:
|
Windows, Oracle Linux, Solaris, and Oracle VM
|
